8K1001+8D1006 Double Bypass Sliding Door

8K1011+8D1006

FEATURES HIGHLIGHTS:

· Reversible

· Frameless Glass Design

· 304 Stainless Steel Handle

· 304 Stainless Steel Door Hinges

· 1 Hinge Door With 1 Fixed Panel & 1 Side Panel,Outward Open

· Up To 20mm Adjustment On Each Side In Width

· Chrome,Black,Silver Matt,Finishes Available

· Bottom Frameless Design

· Easy Clean Treatment Is Optional



SPECIFICATIONS:

DIMENSIONS:

· 800x800/900(8D1006)x1900mm Height,(DOOR 770-790mm Adjustment), 460mm Open Size

· 900x800/900(8D1006)x1900mm Height,(DOOR 870-890mm Adjustment), 460mm Open Size

· 1000x800/900(8D1006)x1900mm Height,(DOOR 970-990mm Adjustment),560mm Open Size

· 1100x800/900(8D1006)x1900mm Height,(DOOR 1070-1090mm Adjustment), 560mm Open Size

· 1200x800/900(8D1006)x1900mm Height,(DOOR 1170-1190mm Adjustment), 610mm Open Size

· Up To 20mm In Width Adjustment

GLASS:

· 8mm Transparent Glass

· Standard Safety Tempered Glass

HARDWARE:

· Chrome finish

· Aluminum Profiles

· U-Type Aluminum Wall Profiles

· F-Type PVC 8mm Water Repellant Profiles

· Full Frameless Glass Design

· 304 Stainless Steel Handle

· 304 Stainless Steel Door Hinges

· With Glass Clips At Top

· With Wall Profiles Caps

STANDARD FEATURES:

· Single Hinge Pivot Door With One(1) Fixed Panel+One(1) Side Panel

· 304 Stainless Steel Handle

· Multifarious Length combination For right Or Left Door Sliding Installation

· Bottom Water Proof Seal Strips(See Drawings)
